Figure 49. Wearstrips.
DRAWBAR WEARSTRIP REPLACEMENT

Maintenance Manual For Motorized Road Grader Model 120M - 5 Page Navigation
  328    329    330    331    332  333  334    335    336    337    338
. .
TM 5-3805-293-23-5
0302
FOLLOW-ON TASKS
000302
1. Install storage box (WP 0258).
2. Remove articulation lock pin (TM 5-3805-293-10).
3. Check adjustment for drawbar wearstrips (WP 0303).
4. Check adjustment for circle guide shoes (WP 0304).
END OF TASK
END OF WORK PACKAGE
0302-41/(42 blank)
