TM 5-3805-293-23-5
FIELD MAINTENANCE
-
CIRCLE ASSEMBLY REPLACEMENT
0
321
Removal, Cleaning and Inspection, Installation
INITIAL SETUP
References
Tools and Special Tools
0
0
Tool Kit, General Mechanic's
WP 0217
0
(WP 0354, Item 83)
WP 0218
0
0
Bracket, Link, 1/2" 4,000 lb (1,800 kg)
WP 0221
0
(WP 0354, Item 13)
0
0
Sling, Nylon (8 ft) (WP 0354, Item 65)
0
0
Socket, Socket Wrench, Wheel Bearing
0
Locknut, 3/4" Dr, 6 pt, 2-9/16" (S0664)
0
(WP 0354, Item 85)
0
Lifting device (2,000-lb [907-kg]
Equipment Condition
0
minimum capacity)
Machine parked (TM 5-3805-293-10)
0
0
Articulation lock pin installed
Materials/Parts
0
(TM 5-3805-293-10)
0
Cap Set, Protective, Dust and Moisture
(WP 0355, Item 7)
Drawings Required
0
0
Rag, Wiping (WP 0355, Item 25)
TM 5-3805-293-24P, Figure 163
0
0
Cotter pin (3)
0
Estimated Time to Complete
Wood block (2)
0
0
12.0 Hr
0
Personnel Required
0
Two
0
REMOVAL
000321
N OT E
Tag and mark hoses to aid in installation.
1. Tip blade completely forward (TM 5-3805-293-10).
0321-1
