24
TM 5-3805-293-23-5
FIELD MAINTENANCE
-
LEFT-HAND JOYSTICK AND ARM SUPPORT REPAIR
0
282
Removal, Disassembly, Cleaning and Inspection, Assembly, Installation
INITIAL SETUP
References
Tools and Special Tools
0
0
Tool Kit, General Mechanic's
0
(WP 0354, Item 83)
0
0
Screwdriver, Torx, T30, 4" Long (S0345)
Equipment Condition
(WP 0354, Item 85)
0
0
Machine parked (TM 5-3805-293-10)
0
Materials/Parts
0
Seat removed (WP 0284)
0
Strap, Tiedown, Electrical Component
Washer bottle removed (WP 0261)
0
(WP 0355, Item 33)
0
Drawings Required
Tag, Marker (WP 0355, Item 35)
0
0
Cotter pin
TM 5-3805-293-24P, Figure 137
0
0
Locknut
0
Estimated Time to Complete
0
Lockwasher
0
4.0 Hr
0
REMOVAL
000282
1. Remove three harness connectors (Figure 1, Item 1) from support (Figure 1, Item 2).
Figure 1. Harness Connectors.
0282
