TM 5-3805-293-23-1
0017
Table 1. Transmission Code (0573-03 to 0967-09) Troubleshooting Procedures - Continued.
CDI FMI CODE
TEST OR INSPECTION
CORRECTIVE ACTION
0596-09 Implement Control
2. Install a jumper wire between har-
Module Abnormal Update
ness connector FA-C22 (WP
Rate - Continued
0009, Figure 47) terminals 64 and
terminal 65.
3. Using digital multimeter, test for
Continuity - Proceed to step 4.
continuity between harness con-
No Continuity - Replace rear chassis
nector FA-C20 (WP 0009, Figure
wiring harness (WP 0188).
113) terminal 10 and terminal 20.
Proceed to step 7.
Resistance should be less than
5.0 ohms.
4. Remove a jumper wire from har-
ness connector FA-C22 (WP
0009, Figure 47) terminals 64 and
terminal 65.
5. Install a jumper wire between har-
ness connector P-C41 (WP 0009,
Figure 68) terminal 10 and termi-
nal 20.
6. Using digital multimeter, test con-
Continuity - Proceed to Test Step 5.
tinuity between harness connec-
No Continuity - Replace cab lower
tor P-C69 (WP 0009, Figure 46)
wiring harness (WP 0266).
terminal 64 and terminal 65.
Connect harness connector FA-C20
There should be no continuity.
(WP 0009, Figure 113) to transmis-
sion ECM J1 (WP 0009, Figure 112).
Proceed to step 7.
7. Using MSD (WP 0006), select
0596-09 Code Remains Active -
Repeat troubleshooting from the
Trans/Chassis 120M and verify
beginning of this diagnostic code.
0596-09 is not active.
0596-09 Code Not Active - Trouble-
shooting complete.
Test Step 5. Test CAN Data Link Cir-
cuit.
1. Using digital multimeter, test for
Resistance Within 50 to 70 Ohms -
continuity between harness con-
Proceed to step 2.
nector P-C39 (WP 0009, Figure
Resistance More Than 70 Ohms or
70) terminal 67 and terminal 68.
Less Than 50 Ohms - Replace cab
Resistance should be 50 to 70 ohms.
lower wiring harness (WP 0266).
Connect harness connector FA-C20
(WP 0009, Figure 113) to transmis-
sion ECM J1 (WP 0009, Figure 112).
Proceed to step 4.
0017-24
