TM 5-3805-293-23-5
0331
COOLANT HEATER INSTALLATION CONTINUED
WARN I N G
Use caution when using adhesives and sealants. Prolonged inhalation of vapors can
cause lung irritation. Contact with skin can cause dermatitis. Wear gloves and safety
goggles and use product in a well-ventilated area away from open flame. If ingested, keep
individual calm and seek medical attention. DO NOT induce vomiting. If contact with skin
or eyes is made, flush thoroughly with water. Dispose of cleanup rags IAW local policy and
ordinances. Failure to follow this warning may result in injury to personnel.
61. Apply sealing compound and install two fittings (Figure 52, Items 3 and 4) on ball valve (Figure 52, Item 5).
Ensure O-ring is on fitting (Figure 52, Item 4).
62. Apply sealing compound and install elbow (Figure 52, Item 2) on fitting (Figure 52, Item 3).
63. Apply sealing compound and install tee (Figure 52, Item 1) on elbow (Figure 52, Item 2). Ensure O-ring is on
tee (Figure 52, Item 1).
Figure 52. Fuel Supply Valve Assembly.
0331
