BATTERY CABLE INSTALLATION CONTINUED
000331
17. Remove tiedown strap (Figure 16, Item 14) and reposition positive battery cable terminal cover (Figure 16,
Item 15). Discard tiedown strap.
18. Remove bolt (Figure 16, Item 3), washer (Figure 16, Item 2), and positive battery cable (Figure 16, Item 13)
from bulkhead connector (Figure 16, Item 1).
19. Remove positive battery cable terminal cover (Figure 16, Item 15) from positive battery cable (Figure 16,
Item 13).
20. Remove bolt (Figure 16, Item 10), washer (Figure 16, Item 11), and clamp (Figure 16, Item 12) from hydraulic
service pack (Figure 16, Item 6).
21. Remove protective cover (Figure 16, Item 5) from bulkhead connector (Figure 16, Item 4).
22. Remove bolt (Figure 16, Item 7), washer (Figure 16, Item 8), and two harness brackets (Figure 16, Item 9) from
hydraulic service pack (Figure 16, Item 6).
Figure 16. Battery Cable Bulkhead Connection.
