TM 5-3805-293-23-5
0337
REMOVAL
000337
1. Release two latches (Figure 1, Item 1).
WARN I N G
Use extreme caution when handling heavy parts. Provide adequate support and use
assistance during procedure. Failure to follow this warning may result in injury or death to
personnel.
N OT E
Battery lid assembly weighs 50 lb (23 kg).
2. With assistance, remove battery lid assembly (Figure 1, Item 2).
Figure 1. Battery Lid.
0337
