LINK ASSEMBLY REPLACEMENT
Figure 1. Link Assembly.

Maintenance Manual For Motorized Road Grader Model 120M - 5 Page Navigation
  523    524    525    526    527  528  529    530    531    532    533
TM 5-3805-293-23-5
0324
REMOVAL
000324
N OT E
The procedure for link assembly replacement is identical for the left and right sides. Right
link assembly replacement is shown in this procedure.
Note quantity and position of shims to aid in installation.
1. Remove four bolts (Figure 1, Item 2), washers (Figure 1, Item 3), two end caps (Figure 1, Item 5), and shims
(Figure 1, Item 4) from link assembly (Figure 1, Item 1).
2. Loosen bolt (Figure 1, Item 7) and nut (Figure 1, Item 6) on link assembly (Figure 1, Item 1).
3. Remove pin lock (Figure 1, Item 8) and pin (Figure 1, Item 9) from link assembly (Figure 1, Item 1).
WARN I N G
Use extreme caution when handling heavy parts. Provide adequate support and use
assistance during procedure. Failure to follow this warning may result in injury or death to
personnel.
N OT E
Link assembly weighs 50 lb (22.6 kg).
0324-2
