INSTALLATION
000292
1. Install washer (Figure 14, Item 2), nut (Figure 14, Item 1), washer (Figure 14, Item 3), bracket (Figure 14,
Item 4), and striker bolt (Figure 14, Item 5) on machine.
Figure 14. Door Striker.
0292
2. Install two hinges (Figure 15, Item 1), four washers (Figure 15, Item 3), and bolts (Figure 15, Item 2) on
machine.
Figure 15. Door and Hinges.
