TM 5-3805-261-23-1
FRONT AND REAR DEFROSTER FANS AND MOUNTING
MAINTENANCE (CCE MACHINE) - CONTINUED
0210 00
17
ASSEMBLY - CONTINUED
7.
Install base (11), bolt (17), washer (18), bracket (19),
washer (25), and new self-locking nut (23).
11
8.
Install bolt (20), two washers (22), resistor (27), clip
16
(16), three washers (21), and new self-locking nut (26)
on support (24).
18
19
20
27
21
21
26
22
25
23
24
397-652
15
9.
Connect wire assembly (14) and install screw (13) to
10
terminal of switch (8).
8
10.
Connect wire assembly (15) and install screw (10) to
14
terminal of switch (8).
11
11.
Position switch (8) in base (11) and install nut (12).
12
13
397-651
0210 00-5
