TM 5-3805-261-10
SECTIONALIZATION FOR AIR TRANSPORT - CONTINUED
0019 00
DISASSEMBLY - CONTINUED
NOTE
Tag cables to assist in connecting to remote control box and when returning to normal configuration.
25.
Disconnect clutch cable (42) on left side of machine and install dust cover. Tag both cable ends as CLUTCH.
42
397-1074
26.
Disconnect three wiring harness connectors (43, 44, and 45) and install dust covers on all connectors.
27.
Remove bolt (46), washer (47), and clamp (48) holding control cables below operator compartment.
28.
Remove control cables from clamp (48).
29.
Install clamp (48), washer (47), and bolt (46) in original location.
43
44
45
46,47,48
397-1075
0019 00-9
