Table 1. Maintenance Allocation Chart (MAC) for 120M Motor Grader - Continued.
(1)
(2)
(3)
(4)
(5)
(6)
Maintenance Level
Field
Sustainment
Tools and
C
F
H
D
Equipment
Group
Component/
Maintenance
Below
Remarks
Reference
Number
Assembly
Function
Crew
Maintainer
Depot
Depot
Code
Code
AA
ENGINE
INSTALLATION
- CONTINUED
AAA
Engine
Test
14.0
1,2,6,7,9,
Assembly
10,20,24,
25,26,33,
35,36,38,
41,44,47,
48,52,54,
56,60,63,
68,70,71,
72,80,81,
82,83,85,
87,88,92,
93,96
AAA
Engine
Replace
33.0
3,14,68,
Assembly
73,83,85,
(Dressed)
93
Rebuild
70
AAA01
Oil Drain Hose
Replace
0.5
83
and Valve
AAA02
Inlet Manifold
Replace
8.0
83,93
AAA03
Fuel Rail
Replace
3.0
83,85,95
AAA04
Secondary Fuel
Replace
1.0
83,85,93
Filter and Base
AAA05
Fuel Injection
Replace
12.5
4,81,82,83,
Pump
85,95,96
AAA06
Fuel Injector
Replace
4.0
67,77,83,
85,92,95
AAA07
Replace
1.5
83,85,95
Manifold
AAA08
Turbocharger
Replace
4.0
83,85
AAA09
Air Inlet Hoses
Replace
3.0
83
and Tubes
AAA10
Waste Gate
Replace
2.5
83
AAA11
Engine Control
Replace
2.0
83
Wiring Harness
